Small Electric Engineering Vehicle

Basic Info.

Model NO.	EMT4
Power	Electric Energy
Load Capacity	4t
Emission Standard	Zero Emission
Drive Wheel	4×2
Engine Capacity	10kw
Seats	≤5
Tire Certification	GCC, DOT
Tire Design	Tube Type Tire
Dumping Type	Front Lifting Style
Condition	New
Overall Weight	1860kg
Cargo Box Plate Thickness	Bottom 5mm Side 3mm
Voltage	72V
Lighting System	Front and Rear LED Lights
Transport Package	Container Transportation
Specification	length3900mm*width 1520mm*height1300mm
Trademark	TYMG
Origin	China
HS Code	8704
Production Capacity	50000pieces/Year

Packaging & Delivery

Package Size 390.00cm * 152.00cm * 130.00cm Package Gross Weight 4000.000kg

Product Description

Shandong TYMG Machinery Co., Ltd. (hereinafter referred to as Shili) was established in 2004 with a registered capital of 10 million yuan. The company is located in Weifang City, Shandong Province, the capital of kites in the world. It is a comprehensive enterprise that focuses on the mining transport vehicle industry and develops in multiple industries. In addition to the R&D, production and sales of the main mining transport vehicles, Shili is now involved in vehicle services, new energy power transportation, and explosion-proof engineering machinery.
TYMG factory covers an area of 40,000 square meters and has more than 10 production lines for stamping, welding, painting, final assembly and inspection; which are controlled by computer and transmitted by mechanization. The main products are metal mining transport trucks, coal mine transport trucks, pure electric mining transport vehicles, mining dump tricycles, engineering dump tricycles, agricultural dump tricycles and so on. The products are mainly for gold mines, iron ore mines, coal mines, tunnel projects, water conservancy construction, special vehicle demand enterprises, mines, rural roads, garden sanitation road maintenance and many other operations. Our product have obtained many national patents and obtained the mine safety certificate issued by the national security inspection department.
Shandong TYMG Heavy Industry Machinery Co., Ltd is a subsidiary of TYMG, It focuses on the development and service of foreign markets. Products are widely sold in more than 30 countries and regions. We have established dealers in Southeast Asia, South America and the rest of the overseas markets are actively expanding.
Shili always adheres to the people-oriented, honest management, upholds the high-end, high-quality and sustainable development route, vigorously promotes quality management and refined management, pays attention to brand and cultural construction, we strive to become a strong competitor of the whole industry chain of mining products for three to five years
EMT4 Mining electric tricycle main technical specifications and parameters

Product model	EMT4
Cargo box Volume	1.6m³
Rated load capacity	4000kg
Unloading height	2650mm
loading height	1300mm
Ground clearance	Front axle 190mm Rear axle 300mm
Turning radius	≤5200mm
Wheel track	1520mm
wheelbase	1520mm
Climbing ability (heavy load)	≤8°
Maximum lift angle of the cargo box	40±2°
Lift motor	1300W
Tire model	Front tire 650-16(mine tire)/rear tire 750-16(mine tire )
shock absorption system	Front: 7peces*70mm width *12mm thickness/ Rear:9pieces*70mmwidth *12mmthickness
Operation system	Medium plate (hydraulic steering)
Control system	Intelligent controller
Lighting system	Front and rear LED lights
Maximum Speed	30km/h
Motor model/power	AC 10KW
No. Battery	12 pieces, 6V, 200Ah maintenance-free
Voltage	72V
Overall dimension (	Length3900mm*Width1520mm*Height1300mm
Cargo box dimension(outer diameter )	Length2600mm*Width1500mm*Height450mm
Cargo box plate thickness	Bottom 5mm side 3mm
Frame	Rectangular tube welding ,50mm*120mm double beam
Overall weight	1860kg
